Ultrasonic Thickness Gauge - QTG I

The Ultrasonic Thickness Gauge - QTG I is a standard model designed for basic measurement applications. It offers high precision with a resolution of 0.001 inches (0.01 mm) and is suitable for measuring the thickness of various metallic and non-metallic materials such as steel, aluminum, titanium, plastics, ceramics, and glass. This economical and user-friendly device is equipped with advanced features like automatic probe frequency recognition and unit zeroing for reliable and accurate operation.

Technical Specifications:

• Display type: 4-digit LCD (128x64 mm) with backlight
• Display resolution: 0.001 inches or 0.01 mm
• Measuring range: 0.040 to 15.75 inches (1 to 400 mm) in steel
• Sound velocity range: 3280-32800 ft/s (1000-9999 m/s) (manually adjustable)
• Operating temperature: 32°F to 122°F (0°C to 50°C)
• Frequency: 5 MHz
• Power supply: Two AAA batteries
• Battery life: Approximately 250 hours with one battery set
• Dimensions: 4-5/8 x 2-3/8 x 1-1/8 inches
• Weight: 7.7 oz (219 g) with batteries

Standard Configuration:

• Main Unit
• Transducer 5 MHz
• Integrated steel calibration plate (4.0 mm)
• Batteries (2 x AAA)
• Ultrasonic Couplant
• Operation Manual
• Certificate
• Carrying Case
• One Year Warranty

Ultrasonic Thickness Gauge QTG I, high-precision thickness measurement, metallic and non-metallic materials, 0.001-inch resolution, 0.01 mm accuracy, affordable ultrasonic gauge, steel calibration plate, basic thickness gauge, user-friendly operation, industrial measurement tool, reliable ultrasonic thickness testing.
