Overview

The QualiSPAbrade™ 1096 is a piece of equipment made specifically for glass coating testing on surfaces like solar panels. As one of our key solar testers, it is put together to line up perfectly with the BS EN 1096-2 method, which looks at how well a coating holds up over time.

The machine copies real-world wear and tear to check the durability of protective finishes, giving you the information needed to confirm how well the product will hold up.

Features & Benefits

• Built for Standard Compliance: Put together to follow the exact steps in the BS EN 1096-2 method, this machine is a go-to tool for dependable glass coating testing.

• Specialized Rubbing Motion: Uses a wool felt pad that turns 20 degrees with every pass, which closely mimics the kind of varied wear that surfaces experience in the real world.

• Flexible Test Setups: You can change the amount of downward force using a set of weights and set the exact number of rubbing cycles, letting you copy a wide variety of real-life situations.

• Handles Large Samples: The testing area is big enough to hold samples up to 400x400mm, making it a good fit for checking bigger pieces of coated glass or full-size solar panel sections.

• Easy Digital Operation: A digital interface lets you set the test speed and number of cycles with just a few button presses, making the setup process quick and straightforward.



Abrasion Tester for Solar Panels and Coated Glass Surfaces Model QualiSPAbrade™ 1096 Technical Specifications

Test Stroke	10-150mm adjustable (common 145mm)
Test Speed	10-120 CPM (digital)
Test Times	1-999,999times
Test Load	Weights 50g, 100g, 200g, 300g, 500g, 1000g each weight Without weight 125g
Rotation Angle	Each round 20°
Max. Test Specimen	400x400mm
Voltage	100 ~ 240V
