Programmable Salt Spray Test Chamber (1280L) - QPSST
Overview
The QPSST Series is designed for laboratories that need more than just a standard box. With extended capacities reaching up to 1280L, this fully programmable salt spray tester provides the space and control necessary for serious corrosion testing. It outperforms standard models by offering superior temperature stability and a smarter, user-focused design that simplifies daily operation.
Key Features
-
Precision Temperature Control: We use advanced air heating technology rather than simple water jackets. Heating wires embedded in the inner plates warm the chamber rapidly, while P.I.D. controls keep the temperature balanced. This ensures the pH and concentration of your spray solution remain stable throughout the test.
-
Rugged Construction: Built to withstand harsh corrosive environments, this salt spray test chamber features a pure titanium inner liner and a stainless steel exterior with a protective paint finish. We also separated the water and electrical components completely to prevent accidental damage to the circuitry.
-
Smart Lid Design: The cabinet cover is angled to prevent condensation from dripping back onto your samples and affecting results. Opening the unit is effortless—an air cylinder lifts the seal cover with a single press of a button.
-
Clog-Free Spray System: Unlike older siphon methods that often get blocked by crystallized salt, our system uses a high-capacity external tank and a peristaltic pump. This delivers a steady, adjustable flow of salt water to the nozzle, ensuring continuous operation without interruptions.
-
Heavy-Duty Sample Racks: The workspace is equipped with a versatile V-shaped glass fiber rack for positioning smaller parts at specific angles. For larger, heavier industrial parts, the lower mesh platform can support distributed weights of over 200 kg per square meter.
-
Advanced Programmability: The TEMI 880 touchscreen controller puts you in charge. You can easily customize spray cycles (continuous or interval), monitor testing parameters, and store up to 360 days of curve data. The unit also includes RS-232 ports, allowing you to manage up to 16 salt spray cabinet units remotely from a PC.
Programmable Salt Spray Test Chambers Technical Specifications:
| Parameter | Value |
|---|---|
| Working Room Temperature Range | RT+5℃～55℃ |
| Humidifying Tower Temperature Range | RT+5℃～65℃ |
| Temperature Uniformity | ≤ ±2℃（No-load） |
| Temperature Stability | ≤ ±0.5℃ （No-load） |
| Temperature Deviation of Working Room | ±1.0℃ |
| Temperature Increasing Rate | RT→50℃ less than 45 minutes (working room) RT→63℃ less than 45 minutes (saturated barrel) |
| Air Supply Requirements | Filtered dry, waterless, and oil-less pressure air, pressure 0.4～0.8Mpa |
|
Ordering Information → Technical Parameters ↓ |
QPSST-450L | QPSST-960L | QPSST-1280L |
| Working Room Size（W×H×D) |
1000 × 650 × 720 (mm) 39.37 × 25.59 × 28.35 (inches) |
1200 × 800 × 1000 (mm) 47.24 × 31.50 × 39.37 (inches) |
1600 × 800 × 1000 (mm) 62.99 × 31.50 × 39.37 (inches) |
|
Working Room Capacity （no including V shape cover） |
450 L | 960 L | 1280 L |
| Overall Size（W×H×D) |
1700 × 1400 × 1000 (mm) 66.92913 × 55.11811 × 39.3701 (inches) |
1900 × 1600 × 1200 (mm) 74.80315 × 62.99213 × 47.24409 (inches) |
2300 × 1600 × 1200 (mm) 90.55118 × 62.99213 × 47.24409 (inches) |
|
Max. Sample Capacity （15cm×7cm） |
65 pcs | 152 pcs | 190 pcs |
| Sprayed solution tank Capacity（L） | 120 | 300 | 300 |
| Collectors | 2 | 2 | 2 |
| Total Power | 3.6 kW | 4.2 kW | 4.6 kW |
| Salt Solution Consumption | 60 L/d | 60 L/d | 70 L/d |
| Compressed Air Consumption | 2 m3/h | 3 m3/h | 3 m3/h |
| Water Consumption in the working room and saturator | 20 L/d | 20 L/d | 20 L/d |
| Power Supply | AC （220±10）V ；50Hz；Single-phase three-line (110V is also available. Please specify when ordering) |
||
